| Hạng mục | LIB-V65535F | LIB-V65535U |
|---|---|---|
| LCD size | 65″ | 65″ |
| Panel type | TFT-LCD | TFT-LCD |
| Light source | LCD Backlight | LCD Backlight |
| Resolution (pixels) | 1920 × 1080 | 3840 × 2160 |
| Brightness | 500 cd/m² (typ.) | 500 cd/m² (typ.) |
| Contrast ratio | 1400:1 (typ.) | 1400:1 (typ.) |
| Pixel pitch (mm) | 0.372 (H) × 0.372 (V) | 0.372 (H) × 0.372 (V) |
| Frame rate | 60 Hz | 60 Hz |
| Viewing angle | 178° (H) / 178° (V) | 178° (H) / 178° (V) |
| Life | 50,000 hrs (min.) | 50,000 hrs (min.) |
| Response time | 8 ms | 8 ms |
| Color saturability | 0.72 | 0.72 |
| Display area (mm) | 1428.48 (W) × 803.52 (H) | 1428.48 (W) × 803.52 (H) |
| Color degree | 16.7M | 16.7M |
| Scalar | MSTAR V53 | MSTAR V53 |
| Voltage | 100~240V, 50~60Hz | 100~240V, 50~60Hz |
| Maximum power | ≤240W | ≤240W |
| Stand-by power | ≤0.5W | ≤0.5W |
| Working temperature | 0°C – 40°C | 0°C – 40°C |
| Storage temperature | -20°C – 60°C | -20°C – 60°C |
| Working humidity | 10% – 90% Non-condensing | 10% – 90% Non-condensing |
| Storage humidity | 20% – 85% Non-condensing | 20% – 85% Non-condensing |
| Display mode | Standard, Soft, User, Beautiful | Standard, Soft, User, Beautiful |
| Normal use time | 20 hours | 20 hours |
| RS232-IN | 1 | 1 |
| USB | 1 | 1 |
| HDMI-IN | 2 | 2 |
| DVI-IN | 1 | 1 |
| RS232 OUT | 2 | 2 |
| Net weight (1 in 1) | 27.7 kg | 27.7 kg |
| Bare dimensions (mm) | 1432.58 × 807.62 × 74.9 | 1432.58 × 807.62 × 74.9 |
| Shell material | Metal | Metal |
| Shell color | Black | Black |
| Bezel (mm) | 3.5 | 3.5 |
| VESA wall mount | 4-M6 screws, 580 × 460 mm | 4-M6 screws, 580 × 460 mm |
| OSD Language | English, Chinese | English, Chinese |
| Remote Control | 1 | 1 |
| Power Cable | 1 | 1 |
| Manual | 1 | 1 |
| RS232 Signal Cable (Network Cable) | 1 | 1 |
| RJ45 to RS232 Interface Socket | 1 | 1 |
| Remote Control Receiver | 1 | 1 |
| Functions | • Using 3-D digital comb filters• Supports 8-bit dual LVDS (1920×1080) HD display• True color OSD, user-friendly operation menu• Mstar ACE-5 automatic color & image enhancement engine• Complete factory set-up mode• 3-D noise reduction technology• Comes with splicing software (supports large screen splicing)• Programmable 12-bit RGB gamma correction technology | Same as LIB-V65535F |
