| Feature | Technical Specification |
|---|---|
| Product Line / Model | LIB-V46 Series, 46″ |
| Screen Size | 46 inches |
| Panel Type | IPS |
| Resolution | 1920 × 1080 |
| Pixel Pitch | 0.53 × 0.53 mm |
| Active Display Area | 1018.08 mm (W) × 572.6 mm (H) |
| Aspect Ratio | 16:9 |
| Brightness | 500 nits |
| Contrast Ratio (Display Panel) | 1200:1 |
| Color Gamut | 72% |
| Haze | 25% (Non-glare) |
| Bezel-to-Bezel Width | 3.5 mm (Ultra Narrow) |
| Viewing Angle | 178° (Horizontal) / 178° (Vertical) |
| Response Time | 8 ms |
| Operating Time | 24/7 continuous operation |
| Input Ports | HDMI 2.0 ×2, DVI-D, DisplayPort 1.2 |
| Output Ports | DP 1.2 Loop Out (Daisy Chain), Audio Out, RS-232C / RJ45 |
| External Control | RS-232C (In/Out), RJ45 Input |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption | Typical: 128 W; Maximum: 160 W; Sleep Mode: < 0.5 W |
| Operating Temperature | 0 °C – 40 °C |
| Operating Humidity | 10% – 80% |
| Dimensions (W × H × D) | 1022 × 577 × 69.9 mm |
| Weight | 15.7 kg |
| VESA Mount | 600 × 400 mm |
| IP Rating | IP5x (Dust Resistant) |
| Special Features | Daisy chain up to 10×10, auto source switching, temperature sensor, hardware/software enhancements |
| Accessories | Remote control, RS232 cable, DP cable, power cord, quick start guide |
