| Model | LIB-IFPI55 | LIB-IFPI65 | LIB-IFPI75 | LIB-IFPI86 | LIB-IFPI98 |
| Screen size | 55” | 65” | 75” | 86” | 98” |
| Bonding technology | Zero Bonding | ||||
| Aspect Ratio | 16:9 | ||||
| Max Visual Area (H/V) (mm) | 1209.6 x 680.4 | 1429 x 804 | 1651 x 929 | 1896 x 1067 | 2159 x 1215 |
| Resolution | 4K UHD 3840 x 2160 | ||||
| Brightness (cd/m2) | 350 | 350 | 350 | 350/450 | 400/450 |
| Contrast ratio (Typ) | 1200:1, 4000:1, 5000:1, 6000:1 | ||||
| Viewing Angles (H/V) | 178o | ||||
| Refresh rate | 60 Hz | ||||
| Response Time | 8 ms | ||||
| Back Light | DLED | ||||
| Life Time | ≥ 50000 (hours) | ||||
| Touch Technology | Infrared Touch | ||||
| Supported Systems | Windows 10/8/7/XP / Android / Linux / Mac OS / Chrome | ||||
| Interactivity | Simultaneous Pen and Touch | ||||
| Touch Accuracy | ± 1mm | ||||
| System Version | Android 11.0 | ||||
| CPU GPU |
Quad core A55 Mali G52MP2 |
||||
| RAM ROM |
4 GB DDR4 / 32 GB DDR4 | ||||
| Bluetooth | Version 5, 2.4 GHz | ||||
| Wifi | Version 802.11ac/b/g/n/a/ax, 2,4GHz/5GHz, Wifi 6.0 | ||||
| Front Interfaces | USB 3.0 x 2, HDMI in x 1, Touch USB x 1, USB Type-C x 1 | ||||
| Rear Interfaces | HDMI IN x 2, USB 3.0 x 2, TOUCH USB x 1, RS232 x 1, USB2.0 x 1, AUDIO IN x 1, OPTICAL OUT x 1, LINE OUT x 1, RJ45 IN x 1, RJ45 OUT x 1 | ||||
| Speaker | 2.0 (2×16 W) | ||||
| Camera | Optional: Built-in Camera 13MP | ||||
| Max. Power Consumption | 330W | 400W | 400W | 550W | 550W |
| Voltage | 100-240V～ 50/60Hz 4A | ||||
| Working Temperature | 0° – 40°C | ||||
| Working Humidity | 10% – 90%RH | ||||
| Product Dimensions (mm) | 1263×776.8×87.6 | 1484.6×903.08×87.21 | 1706.76 x 1027.32 x 87.31 | 1952.96 1167.77 87.18 | 2216.8 x 1314.28 x 104.31 |
| VESA Wall Mount (mm) | 400 x 200 | 500 x 400 | 600 x 400 | 800 x 400 | 1000 x 400 |
| Wall Screw (mm) | M8 x 25 | M8 x 20 | |||
| Accessories | Power Cable, Stylus pen, Wall mout Braket, remote control, User Manual | ||||
